DatasheetProduct Attributes
| TYPE | DESCRIPTION |
|---|---|
| Category: | Isolators Isolators – Gate Drivers |
| Mfr: | Infineon Technologies |
| Series: | EiceDriver™ |
| Packaging: | Tape & Reel Cut Tape (CT) Digi-Reel® |
| Part Status: | Active |
| Technology: | Magnetic Coupling |
| Number of Channels: | 1 |
| Propagation Delay tpLH / tpHL (Max): | – |
| Pulse Width Distortion (Max): | – |
| Rise / Fall Time (Typ): | 10ns, 9ns |
| Current – Peak Output: | – |
| Voltage – Forward (Vf) (Typ): | – |
| Voltage – Output Supply: | 10V ~ 35V |
| Grade: | – |
| Qualification: | – |
| Operating Temperature: | -40°C ~ 150°C (TJ) |
| Mounting Type: | Surface Mount |
| Package / Case: | 8-SOIC (0.154″, 3.90mm Width) |
| Supplier Device Package: | PG-DSO-8-51 |
| Base Product Number: | 1EDI20 |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets: | 1EDI20N12AF |
| Other Related Documents: | Fundamentals of Power Semiconductors |
| Environmental Information: | RoHS Certificate |
| Featured Product: | Data Processing Systems |
| PCN Other: | Mult Dev Lot Code Standardization 11/Nov/2022 |
| HTML Datasheet: | 1EDI20N12AF |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status: |
ROHS3 Compliant
|
| Moisture Sensitivity Level (MSL): |
3 (168 Hours)
|
| REACH Status: |
REACH Unaffected
|
| ECCN: |
EAR99
|
| HTSUS: |
8542.39.0060
|
Additional Resources
| Attribute | Description |
|---|---|
| Other Names: |
1EDI20N12AFXUMA1CT
1EDI20N12AFXUMA1-ND 1EDI20N12AFXUMA1TR SP001222658 1EDI20N12AFXUMA1DKR |
| Standard Package: |
2,500
|
