DatasheetProduct Attributes
| TYPE | DESCRIPTION |
|---|---|
| Category: | Discrete Semiconductor Products Transistors FETs, MOSFETs Single FETs, MOSFETs |
| Mfr: | onsemi |
| Series: | – |
| Packaging: | Tape & Reel Cut Tape (CT) Digi-Reel® |
| Part Status: | Active |
| FET Type: | N-Channel |
| Technology: | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss): | 60 V |
| Current – Continuous Drain (Id) @ 25°C: | 260mA (Ta) |
| Drive Voltage (Max Rds On, Min Rds On): | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs: | 2.5Ohm @ 240mA, 10V |
| Vgs(th) (Max) @ Id: | 2.5V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs: | 0.81 nC @ 5 V |
| Vgs (Max): | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds: | 26.7 pF @ 25 V |
| FET Feature: | – |
| Power Dissipation (Max): | 300mW (Tj) |
| Operating Temperature: | -55°C ~ 150°C (TJ) |
| Mounting Type: | Surface Mount |
| Supplier Device Package: | SOT-23-3 (TO-236) |
| Package / Case: | TO-236-3, SC-59, SOT-23-3 |
| Base Product Number: | 2N7002 |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets: | 2N7002E Datasheet |
| Environmental Information: | |
| Featured Product: | Cordless Power Tools |
| PCN Design/Specification: | |
| PCN Assembly/Origin: | Mult Dev Mold Comp Chg 1/Apr/2020 |
| PCN Packaging: | New taping option 15/May/2019 |
| HTML Datasheet: | 2N7002E Datasheet |
| EDA Models: | 2N7002ET1G Models |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status: |
ROHS3 Compliant
|
| Moisture Sensitivity Level (MSL): |
1 (Unlimited)
|
| REACH Status: |
REACH Unaffected
|
| ECCN: |
EAR99
|
| HTSUS: |
8541.21.0095
|
Additional Resources
| Attribute | Description |
|---|---|
| Other Names: |
2N7002ET1G-ND
2N7002ET1GOSDKR 2N7002ET1GOSCT 2832-2N7002ET1G 2156-2N7002ET1G 2N7002ET1GOSTR ONSONS2N7002ET1G |
| Standard Package: |
3,000
|
