DatasheetProduct Attributes
| TYPE | DESCRIPTION |
|---|---|
| Category: | Inductors, Coils, Chokes Arrays, Signal Transformers |
| Manufacturer: | Würth Elektronik |
| Series: | WE-DD |
| Packaging: | Tape & Reel Cut Tape (CT) Digi-Reel® |
| Part Status: | Active |
| Number of Coils: | 2 |
| Inductance – Connected In Parallel: | 11 µH |
| Inductance – Connected In Series: | 44 µH |
| Tolerance: | ±20% |
| Current Rating – Parallel: | 800 mA |
| Current Rating – Series: | 400 mA |
| Current Saturation – Parallel: | 1.8 A |
| Current Saturation – Series: | 900 mA |
| DC Resistance (DCR) – Parallel: | 260mOhm Max |
| DC Resistance (DCR) – Series: | – |
| Shielding: | Shielded |
| Ratings: | – |
| Operating Temperature: | -40°C ~ 125°C |
| Mounting Type: | Surface Mount |
| Package / Case: | Nonstandard |
| Size / Dimension: | 0.287″ L x 0.287″ W (7.30mm x 7.30mm) |
| Height: | 0.189″ (4.80mm) |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets: | 744877220 |
| Product Training Modules: | Coupled Inductors for SEPIC Converter Applications |
| Environmental Information: | RoHS Cert |
| Design Resources: | 744877220 Red Expert Design Tool |
| Featured Product: | WE-DD Coupled Inductors Series |
| CAD Models: | 744877220 Models |
| PCN Design/Specification: | |
| PCN Packaging: | Mult Devs – packaging label 1/OCT/2020 |
| PCN Other: | Mult Devices Label 22/Dec/2021 |
| HTML Datasheet: | 744877220 |
| EDA Models: | 744877220 Models |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status: |
ROHS3 Compliant
|
| Moisture Sensitivity Level (MSL): |
1 (Unlimited)
|
| REACH Status: |
REACH Unaffected
|
| ECCN: |
EAR99
|
| HTSUS: |
8504.50.4000
|
Additional Resources
| Attribute | Description |
|---|---|
| Other Names: |
732-2313-6
732-2313-1 732-2313-2 |
| Standard Package: |
1,000
|
