760308101214

Manufacturer Product Number: 760308101214
Manufacturer:Würth Elektronik
Description: RX 1 COIL 3 LAYER 26UH 1.1A
Manufacturer Standard Lead Time: 24 Weeks
Datasheet:Datasheet
Detailed Description: 1 Coil, 3 Layer 26µH Wireless Charging Coil Receiver 520mOhm Max

Product Attributes

TYPE DESCRIPTION
Category: Inductors, Coils, Chokes
Wireless Charging Coils
Manufacturer: Würth Elektronik
Series: WE-WPCC
Packaging: Tray
Part Status: Active
Function: Receiver
Type: 1 Coil, 3 Layer
Inductance: 26µH
Tolerance: ±10%
DC Resistance (DCR): 520mOhm Max
Q @ Freq: 25 @ 125kHz
Current Rating (Amps): 1.1A
Current – Saturation (Isat): 2A
Frequency – Self Resonant: 11MHz
Operating Temperature: -20°C ~ 105°C
Size / Dimension: 0.75″ Dia x 0.03″ H (19.0mm x 0.8mm)

Documents & Media

Resource Type Link
Product Training Modules:
Video File:

Wurth Wireless Power Charging Coils | Digi-Key Daily

Wurth Elektronik illustrates Wireless Power Transfer (WPT)

WEbinar Powered by Digi-Key: Design and Optimization of a Simultaneous WPT and NFC System

Environmental Information: RoHS Cert
Design Resources: 760308101214 Red Expert Design Tool
Featured Product: Wireless Power Solutions
CAD Models: 760308101214 Models
PCN Assembly/Origin: WE-WPCC Assembly Chgs 17/Jul/2019
PCN Other: Mult Devices Label 22/Dec/2021
HTML Datasheet: 760308101214 Drawing
Product Drawings: 760308101214 Drawing

Environmental & Export Classifications

Attribute Description
RoHS Status:
ROHS3 Compliant
Moisture Sensitivity Level (MSL):
Not Applicable
REACH Status:
REACH Unaffected
ECCN:
EAR99
HTSUS:
8504.50.4000

Additional Resources

Attribute Description
Other Names:
732-8240
Standard Package:
24
