DatasheetProduct Attributes
| TYPE | DESCRIPTION |
|---|---|
| Category: | Inductors, Coils, Chokes Wireless Charging Coils |
| Manufacturer: | Würth Elektronik |
| Series: | WE-WPCC |
| Packaging: | Tray |
| Part Status: | Active |
| Function: | Receiver |
| Type: | 1 Coil, 1 Layer, Bifilar |
| Inductance: | 12µH |
| Tolerance: | ±10% |
| DC Resistance (DCR): | 160mOhm |
| Q @ Freq: | 33 @ 125kHz |
| Current Rating (Amps): | 2.9A |
| Current – Saturation (Isat): | 6A |
| Frequency – Self Resonant: | 25MHz |
| Operating Temperature: | -20°C ~ 105°C |
| Size / Dimension: | 1.89″ L x 1.26″ W x 0.04″ H (48.0mm x 32.0mm x 1.0mm) |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets: | 760308103202 WE-WPCC Receiver Coil |
| Product Training Modules: | |
| Video File: |
Wurth Wireless Power Charging Coils | Digi-Key Daily Wurth Elektronik illustrates Wireless Power Transfer (WPT) WEbinar Powered by Digi-Key: Wireless Power Transfer WEbinar Powered by Digi-Key: Design and Optimization of a Simultaneous WPT and NFC System Wireless Power Transfer Advanced Coil Knowledge – We Cut the Cord! |
| Environmental Information: | RoHS Cert |
| Design Resources: | 760308103202 Red Expert Design Tool |
| Featured Product: | |
| CAD Models: | 760308103202 Models |
| PCN Design/Specification: | 760308103202 08/Oct/2015 |
| PCN Assembly/Origin: | WE-WPCC Assembly Chgs 17/Jul/2019 |
| PCN Other: | Mult Devices Label 22/Dec/2021 |
| HTML Datasheet: | 760308103202 WE-WPCC Receiver Coil |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status: |
ROHS3 Compliant
|
| Moisture Sensitivity Level (MSL): |
Not Applicable
|
| REACH Status: |
REACH Unaffected
|
| ECCN: |
EAR99
|
| HTSUS: |
8504.50.4000
|
Additional Resources
| Attribute | Description |
|---|---|
| Other Names: |
1297-1114
732-5257 1297-1114-ND |
| Standard Package: |
48
|
