DatasheetProduct Attributes
| TYPE | DESCRIPTION |
|---|---|
| Category: | Development Boards, Kits, Programmers Evaluation Boards Evaluation and Demonstration Boards and Kits |
| Manufacturer: | SparkFun Electronics |
| Series: | – |
| Packaging: | Bulk |
| Part Status: | Active |
| Type: | Interface |
| Function: | Logic-Level Translator |
| Embedded: | No |
| Utilized IC / Part: | BSS138 |
| Primary Attributes: | 4-Channel (Quad) |
| Secondary Attributes: | – |
| Contents: | Board(s) |
| Note: | – |
| Supplied Contents: | Board(s) |
| Base Product Number: | BSS138 |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets: | |
| Design Resources: | |
| HTML Datasheet: | Bi-Directional Logic Level Converter Hookup Guide |
| EDA Models: | BOB-12009 Models |
| Projects: | Satellite Transceiver Kit – Swarm M138 Hookup Guide |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status: |
ROHS3 Compliant
|
| Moisture Sensitivity Level (MSL): |
1 (Unlimited)
|
| REACH Status: |
REACH Unaffected
|
| ECCN: |
EAR99
|
| HTSUS: |
8473.30.1180
|
Additional Resources
| Attribute | Description |
|---|---|
| Other Names: |
12009
1568-1209 |
| Standard Package: |
1
|
