DatasheetProduct Attributes
| TYPE | DESCRIPTION |
|---|---|
| Category: | Crystals, Oscillators, Resonators Resonators |
| Manufacturer: | Murata Electronics |
| Series: | CERALOCK® CSTCR |
| Packaging: | Tape & Reel Cut Tape (CT) Digi-Reel® |
| Part Status: | Active |
| Type: | Ceramic |
| Frequency: | 4 MHz |
| Frequency Stability: | ±0.2% |
| Frequency Tolerance: | ±0.5% |
| Features: | Built in Capacitor |
| Capacitance: | 15 pF |
| Impedance: | 60 Ohms |
| Operating Temperature: | -20°C ~ 80°C |
| Mounting Type: | Surface Mount |
| Package / Case: | 3-SMD, Non-Standard |
| Size / Dimension: | 0.177″ L x 0.079″ W (4.50mm x 2.00mm) |
| Height: | 0.047″ (1.19mm) |
| Base Product Number: | CSTCR |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets: | CERALOCK® CSBLA Series |
| Video File: |
The Role of Oscillation Circuit Components The Measurement Process for the Oscillation Margin The Measurement Process for the Drive Level |
| Design Resources: | CSTCR4M00G53-R0 SimSurfing Design Tool |
| EDA Models: | CSTCR4M00G53-R0 Models |
| Manuals: | CERALOCK® Series Appl Manual |
| Part Numbering Guide: | CERALOCK® Part Numbering |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status: |
ROHS3 Compliant
|
| Moisture Sensitivity Level (MSL): |
1 (Unlimited)
|
| REACH Status: |
REACH Affected
|
| ECCN: |
EAR99
|
| HTSUS: |
8548.00.0000
|
Additional Resources
| Attribute | Description |
|---|---|
| Other Names: |
490-1200-6
490-1200-2 490-1200-1 CSTCR4M00G53R0 |
| Standard Package: |
3,000
|
