DatasheetProduct Attributes
| TYPE | DESCRIPTION |
|---|---|
| Category: | Development Boards, Kits, Programmers Evaluation Boards Analog to Digital Converters (ADCs) Evaluation Boards |
| Manufacturer: | DFRobot |
| Series: | – |
| Packaging: | Bulk |
| Part Status: | Active |
| Number of A/D Converters: | 1 |
| Number of Bits: | 18 |
| Sampling Rate (Per Second): | 3.75 ~ 240 |
| Data Interface: | I2C |
| Input Range: | ±VREF |
| Power (Typ) @ Conditions: | – |
| Utilized IC / Part: | MCP3424 |
| Supplied Contents: | Board(s) |
| Note: | – |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets: | |
| Software Download: | |
| Design Resources: | MCP3424 18 Bit Schematic |
| HTML Datasheet: | |
| Scheme-It: | DFR0316 Scheme-It® |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status: |
Not applicable
|
| Moisture Sensitivity Level (MSL): |
1 (Unlimited)
|
| ECCN: |
EAR99
|
| HTSUS: |
8473.30.1180
|
Additional Resources
| Attribute | Description |
|---|---|
| Other Names: |
1738-1178
|
| Standard Package: |
1
|
