DatasheetProduct Attributes
| TYPE | DESCRIPTION |
|---|---|
| Category: | Filters Common Mode Chokes |
| Manufacturer: | Murata Electronics |
| Series: | DLM0NS |
| Packaging: | Tape & Reel Cut Tape (CT) Digi-Reel® |
| Part Status: | Active |
| Filter Type: | Signal Line |
| Number of Lines: | 2 |
| Impedance @ Frequency: | 90 Ohms @ 100 MHz |
| Current Rating (Max): | 100mA |
| DC Resistance (DCR) (Max): | 4Ohm |
| Voltage Rating – DC: | 5V |
| Voltage Rating – AC: | – |
| Operating Temperature: | -40°C ~ 85°C |
| Ratings: | – |
| Approval Agency: | – |
| Features: | – |
| Mounting Type: | Surface Mount |
| Size / Dimension: | 0.033″ L x 0.026″ W (0.85mm x 0.65mm) |
| Height (Max): | 0.020″ (0.50mm) |
| Package / Case: | 0302 (0806 Metric), 4 Lead |
| Base Product Number: | DLM0NSM |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets: | DLM0NSzzzzHY2z Spec |
| Product Training Modules: | Common Mode Chokes |
| Design Resources: | DLM0NSM900HY2D SimSurfing Design Tool |
| HTML Datasheet: | DLM0NSzzzzHY2z Spec |
| EDA Models: | DLM0NSM900HY2D Models |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status: |
ROHS3 Compliant
|
| Moisture Sensitivity Level (MSL): |
1 (Unlimited)
|
| REACH Status: |
REACH Unaffected
|
| ECCN: |
EAR99
|
| HTSUS: |
8548.00.0000
|
Additional Resources
| Attribute | Description |
|---|---|
| Other Names: |
490-DLM0NSM900HY2DDKR
490-DLM0NSM900HY2DCT 490-DLM0NSM900HY2DTR |
| Standard Package: |
10,000
|
