DatasheetProduct Attributes
| TYPE | DESCRIPTION |
|---|---|
| Category: | Capacitors Aluminum Electrolytic Capacitors |
| Mfr: | Panasonic Electronic Components |
| Series: | S |
| Packaging: | Tape & Reel Cut Tape (CT) Digi-Reel® |
| Part Status: | Not For New Designs |
| Capacitance: | 10 µF |
| Tolerance: | ±20% |
| Voltage – Rated: | 16 V |
| ESR (Equivalent Series Resistance): | – |
| Lifetime @ Temp.: | 2000 Hrs @ 85°C |
| Operating Temperature: | -40°C ~ 85°C |
| Polarization: | Polar |
| Ratings: | AEC-Q200 |
| Applications: | Automotive |
| Ripple Current @ Low Frequency: | 28 mA @ 120 Hz |
| Ripple Current @ High Frequency: | 47.6 mA @ 10 kHz |
| Lead Spacing: | – |
| Size / Dimension: | 0.157″ Dia (4.00mm) |
| Height – Seated (Max): | 0.217″ (5.50mm) |
| Surface Mount Land Size: | 0.169″ L x 0.169″ W (4.30mm x 4.30mm) |
| Mounting Type: | Surface Mount |
| Package / Case: | Radial, Can – SMD |
| Base Product Number: | EEE-1CA |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets: | S Series, Type V |
| Product Training Modules: | LED Lighting Components |
| Environmental Information: | RoHS S-V Series |
| CAD Models: | EEE-1CA100SR Models |
| PCN Packaging: | Multiple SMD Lytic Series 05/Jul/2017 |
| PCN Part Status Change: | Mult Series NRND 20/Jul/2022 |
| HTML Datasheet: | S Series, Type V |
| EDA Models: | EEE-1CA100SR Models |
| Part Numbering Guide: | Aluminum Elect Caps, Part Number System |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status: |
ROHS3 Compliant
|
| Moisture Sensitivity Level (MSL): |
1 (Unlimited)
|
| REACH Status: |
REACH Unaffected
|
| ECCN: |
EAR99
|
| HTSUS: |
8532.22.0020
|
Additional Resources
| Attribute | Description |
|---|---|
| Other Names: |
PCE3878TR
EEE1CA100SR PCE3878CT PCE3878DKR |
| Standard Package: |
2,000
|
