DatasheetProduct Attributes
| TYPE | DESCRIPTION |
|---|---|
| Category: | Capacitors Trimmers, Variable Capacitors |
| Manufacturer: | EW Electronics |
| Series: | SGC3S |
| Packaging: | Tape & Reel Cut Tape (CT) Digi-Reel® |
| Part Status: | Active |
| Capacitance Range: | 3 ~ 10pF |
| Adjustment Type: | Top |
| Voltage – Rated: | 100 V |
| Dielectric Material: | Ceramic |
| Q @ Freq: | 600 @ 1MHz |
| Size / Dimension: | 0.177″ L x 0.126″ W (4.50mm x 3.20mm) |
| Height – Seated (Max): | 0.061″ (1.54mm) |
| Operating Temperature: | -40°C ~ 85°C |
| Mounting Type: | Surface Mount |
| Features: | Low Profile |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets: | SGC3S Series Spec |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status: |
ROHS3 Compliant
|
| Moisture Sensitivity Level (MSL): |
1 (Unlimited)
|
| REACH Status: |
REACH Unaffected
|
| ECCN: |
EAR99
|
| HTSUS: |
8532.30.0010
|
Additional Resources
| Attribute | Description |
|---|---|
| Other Names: |
2447-SGC3S100DKR
2447-SGC3S100TR 2447-SGC3S100CT |
| Standard Package: |
1,000
|
