DatasheetProduct Attributes
| TYPE | DESCRIPTION |
|---|---|
| Category: | Discrete Semiconductor Products Transistors FETs, MOSFETs FET, MOSFET Arrays |
| Manufacturer: | Rohm Semiconductor |
| Series: | – |
| Packaging: | Tape & Reel Cut Tape (CT) Digi-Reel® |
| Part Status: | Active |
| Technology: | MOSFET (Metal Oxide) |
| Configuration: | 2 N-Channel (Dual) |
| FET Feature: | Logic Level Gate, 0.9V Drive |
| Drain to Source Voltage (Vdss): | 50V |
| Current – Continuous Drain (Id) @ 25°C: | 200mA |
| Rds On (Max) @ Id, Vgs: | 2.2Ohm @ 200mA, 4.5V |
| Vgs(th) (Max) @ Id: | 800mV @ 1mA |
| Gate Charge (Qg) (Max) @ Vgs: | – |
| Input Capacitance (Ciss) (Max) @ Vds: | 26pF @ 10V |
| Power – Max: | 120mW |
| Operating Temperature: | 150°C (TJ) |
| Mounting Type: | Surface Mount |
| Package / Case: | 6-TSSOP, SC-88, SOT-363 |
| Supplier Device Package: | UMT6 |
| Base Product Number: | UM6K34 |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets: | UM6K34NTCN |
| Other Related Documents: | |
| Environmental Information: | |
| EDA Models: | UM6K34NTCN Models |
| Simulation Models: | UM6K34N Spice Model |
| Reliability Documents: | UMT6 MOS Reliability Test |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status: |
ROHS3 Compliant
|
| Moisture Sensitivity Level (MSL): |
1 (Unlimited)
|
| REACH Status: |
REACH Unaffected
|
| ECCN: |
EAR99
|
| HTSUS: |
8541.21.0095
|
Additional Resources
| Attribute | Description |
|---|---|
| Other Names: |
UM6K34NTCNTR
UM6K34NTCNCT UM6K34NTCNDKR |
| Standard Package: |
3,000
|
