DatasheetProduct Attributes
| TYPE | DESCRIPTION |
|---|---|
| Category: | Inductors, Coils, Chokes Wireless Charging Coils |
| Manufacturer: | TDK Corporation |
| Series: | WR |
| Packaging: | Tray |
| Part Status: | Active |
| Function: | Receiver |
| Type: | 1 Coil, 2 Layer |
| Inductance: | 11µH |
| Tolerance: | ±5% |
| DC Resistance (DCR): | 350mOhm |
| Q @ Freq: | – |
| Current Rating (Amps): | – |
| Current – Saturation (Isat): | – |
| Frequency – Self Resonant: | – |
| Operating Temperature: | – |
| Size / Dimension: | 0.79″ Dia x 0.03″ H (20.0mm x 0.8mm) |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets: | WR202010-18M8-ID |
| Environmental Information: | TDK Corporation Environment Page |
| HTML Datasheet: | WR202010-18M8-ID |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status: |
ROHS3 Compliant
|
| Moisture Sensitivity Level (MSL): |
Not Applicable
|
| REACH Status: |
REACH Unaffected
|
| ECCN: |
EAR99
|
| HTSUS: |
8536.50.9065
|
Additional Resources
| Attribute | Description |
|---|---|
| Other Names: |
445-174579
|
| Standard Package: |
45
|
