Product Attributes
| TYPE | DESCRIPTION |
|---|---|
| Category: | Inductors, Coils, Chokes Wireless Charging Coils |
| Manufacturer: | TDK Corporation |
| Series: | WT |
| Packaging: | Tray |
| Part Status: | Not For New Designs |
| Function: | Transmitter |
| Type: | 1 Coil, 1 Layer |
| Inductance: | 6.3µH |
| Tolerance: | – |
| DC Resistance (DCR): | 60mOhm |
| Q @ Freq: | – |
| Current Rating (Amps): | – |
| Current – Saturation (Isat): | – |
| Frequency – Self Resonant: | – |
| Operating Temperature: | – |
| Size / Dimension: | 1.97″ Dia x 0.15″ H (50.0mm x 3.8mm) |
Documents & Media
| Resource Type | Link |
|---|---|
| Environmental Information: | TDK Corporation Environment Page |
| HTML Datasheet: | WT505090-10K2-A11-G Overview |
| EDA Models: | WT505090-10K2-A11-G Models |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status: |
ROHS3 Compliant
|
| Moisture Sensitivity Level (MSL): |
1 (Unlimited)
|
| REACH Status: |
REACH Unaffected
|
| ECCN: |
EAR99
|
| HTSUS: |
8543.70.9860
|
Additional Resources
| Attribute | Description |
|---|---|
| Other Names: |
445-16095
|
| Standard Package: |
13
|
